How to Panel Line a Gundam Model Using a Gundam Marker Pen

Building and customizing Gundam models is a rewarding and intricate hobby, and one of the most popular techniques to enhance the appearance of your kit is panel lining. Panel lining not only brings out the fine details of your model but also gives it a more realistic and dynamic look. Among the various tools available for panel lining, the Gundam Marker Pen is one of the most accessible and beginner-friendly options. In this article, we’ll guide you through the process of panel lining a Gundam model using a Gundam Marker Pen, providing you with the knowledge you need to bring out the best in your model.

What is Panel Lining?

Panel lining is the technique of adding lines or darker shades into the crevices of a model kit. It helps define the shape and structure of the model, making the individual parts stand out more. This technique can make the difference between a basic-looking Gundam and one that looks more professional, sharp, and impressive.

Panel lining is especially important for Gundam kits because of the complex details in their designs. Without panel lines, the finer elements can be easily lost, leaving the model looking flat and lifeless.

Why Use a Gundam Marker Pen?

There are several tools and methods you can use to panel line a Gundam model, but the Gundam Marker Pen stands out for its simplicity, accessibility, and effectiveness. Gundam Marker Pens are designed specifically for modelers, with ink that is fast-drying, water-based, and easy to control. The fine tip allows for precision work, making it an ideal choice for beginners and experts alike.

Here are some reasons why the Gundam Marker Pen is ideal for panel lining:

• Convenience: Easy to use, no need for brushes or airbrushes.
• Precision: The fine tip allows for detailed work in small crevices.
• Accessible: Available in various colors and suitable for beginners.
• Non-toxic: Safe to use, especially for those working indoors.

Tools You Will Need

Before you start panel lining, ensure you have the following tools at hand:

1. Gundam Marker Pen (Panel Liner): Choose a pen with a fine or ultra-fine tip. You’ll also want to select a color that matches the tone of your Gundam model, usually black or brown for most kits.
2. Gundam Model Kit: Make sure your Gundam model is assembled and free from dust.
3. Paper Towel or Tissue: For cleaning up any excess ink.
4. Cotton Swabs or Q-tips: For wiping off any excess or unwanted ink.
5. Rubbing Alcohol (optional): Helps in cleaning up stubborn excess ink or fixing mistakes.
6. Masking Tape (optional): For protecting areas where you don't want any ink.

Step-by-Step Guide to Panel Lining with a Gundam Marker Pen

Step 1: Prepare Your Model

Before starting, ensure that your Gundam model is fully assembled. If you haven't done so yet, remove any excess sprue marks, and make sure the parts are clean. Dust or debris can affect how well the panel liner adheres to the surface.

Step 2: Choose the Right Gundam Marker

Gundam Marker Pens come in various colors. For most models, a basic black or gray panel liner is often the most suitable. However, depending on the color scheme of your Gundam, you may want to use different shades (brown for lighter-colored models, or even blue for special designs). If you’re unsure, black is always a safe bet.

Step 3: Begin Panel Lining

Start with the main body of the Gundam. Gently shake the marker to ensure the ink flows smoothly. Then, carefully run the pen along the panel lines and recesses of your model. The ink will fill the crevices, highlighting the details.

Tips for a successful panel lining:

• Work in sections: Instead of doing the entire kit at once, focus on one part at a time to maintain precision.
• Apply a light amount of pressure: Let the pen’s tip do the work. Excessive pressure can lead to uneven lines.
• Avoid rushing: Take your time to carefully follow the panel lines on your model.

Step 4: Use a Cotton Swab to Clean Excess Ink

Once you’ve applied the panel lining to a section, wait a few moments for the ink to dry. If there’s any excess ink on the surface, you can use a cotton swab or tissue to wipe it off. Be sure to wipe in the direction of the panel line to avoid removing the ink from the crevice itself.

If any ink remains stubbornly on the surface, a tiny dab of rubbing alcohol on a cotton swab can help clean it up. Be cautious not to use too much, as it could affect the surrounding paint or surface finish.

Step 5: Let the Model Dry

Once you’ve completed all the panel lining, allow the model to dry for 15-30 minutes, depending on the humidity and temperature. Make sure to check the model for any missed spots or excess ink before proceeding.

Step 6: Optional Finishing Touches

For an even more detailed and refined look, you can use a lighter color of Gundam Marker for finer panel lines or accents. A white or gray panel liner can be applied to areas that need a softer, subtler finish.

You may also choose to add additional effects like weathering or washes to further enhance the depth and realism of the panel lining.

Tips for a Perfect Panel Line Finish

1. Control Ink Flow: If you notice too much ink flowing from the pen, gently blot the tip on a tissue to avoid excess marks.
2. Test on a Scrapped Piece: Before applying the panel liner to your main model, test it on a scrap piece or an unused part of your model to ensure the ink flows correctly and that it complements your kit’s colors.
3. Work in Small Sections: Applying panel liner to smaller sections allows you to control the process better and avoid mistakes that can be harder to fix on larger areas.
4. Don’t Overdo It: While panel lining enhances the details, too much can make the model look overly busy. Keep it subtle for the best effect.

Conclusion

Panel lining with a Gundam Marker Pen is one of the most effective and beginner-friendly ways to add depth and detail to your Gundam model. It’s a simple process that requires patience and precision, but with the right tools and techniques, you can take your Gundam kit from good to great. By following the steps outlined in this guide, you'll be able to make your model pop, highlighting the fine details that make Gundam kits truly spectacular.

Whether you’re a novice or an experienced modeler, panel lining with a Gundam Marker Pen is a skill that every Gundam enthusiast should master. With a bit of practice, you'll quickly see how this technique can elevate the overall appearance of your kits. Happy modeling!
